KT42JM06-551, KT SERIES,
Type
KT
Series
, 3 phase Hybrid Stepping Motor
Product
Type
Stepper Motor
Series
3 Phase KT
Motor Frame Size
NEMA 17
No. of Phases
3
Step Angle
0.6 deg./step
Voltage
3.12 V
Current per 2 Phase
2.4 A
Winding Resistance/2 Phase
1.30 Ω
Inductance/2 Phase
1.3 mH
Holding Torque
25.5 oz·in180 mN·m
Detent Torque
1.1 oz·in8 mN·m
Standard Size
42 x 40 mm1.65 x 1.58 in.
Rotor Inertia
60 g·cm²0.33 oz·in²
Drive Method
Bipolar
Weight
310 g0.68 lb
Insulation Class
Jis Class E (120ºC/248ºF) (UL Value : Class B 130ºC/266ºF)
Insulation Resistance (Motor Section)
500 VDC, 100 MO min.
Dielectric Strength
500 VAC, 50 HZ, 1 min.
Operating Temperature Range
-10 to 50 ºC
Allowable Temperature Rise
70 ºK
