- 3 Pin 2 Position Panel Mount Micro Vertical Spdt Slide Switch High Knob
Mreeco
3 Pin 2 Position Panel Mount Micro Vertical Spdt Slide Switch High Knob
Rs 20
In stock
Features:Product Name Slide SwitchModel SS12D01Type 1 Pole 2 Throw, 2 PositionTerminal Quantity 3 PcsWorking Power 0.3A 50V DCContact Resistance 30mΩ MaxInsulation Resistance 100mΩ Min at 500V DCWithstand Voltage AC 5...
Ask about this product on WhatsApp- Fast deliveryFree shipping on prepaid orders above Rs. 10,000
- Secure payment100% secure payments by Meezan Bank
- SupportMonday to Saturday, 11:00 AM to 8:00 PM
- ReturnsSee our return and refund policy
Description
Features:
Product Name Slide Switch Model SS12D01 Type 1 Pole 2 Throw, 2 Position Terminal Quantity 3 Pcs Working Power 0.3A 50V DC Contact Resistance 30mΩ Max Insulation Resistance 100mΩ Min at 500V DC Withstand Voltage AC 500V for 1 min Terminal Size(Each One) 3.3 x 0.5mm / 0.13" x 0.02"( L * W) Pins Pitch 2.54mm / 0.1" Main Body Size(not Include Knob & Pins) 8.6 x 4.4 x 4mm / 0.33" x 0.17" x 0.16"(L * W* H) Switch Total Size 8.6 x 4.4 x 12.2mm / 0.33" x 0.17" x 0.48"(L * W* H) Knob Size 2 x 2 x 5.3mm / 0.07" x 0.07" x 0.2"(L * W * H) Material(External) Plastic, Metal Main Color Silver Tone, Black Weight 9gPackage Includes:
- 3 Pin switch
Specifications
| Brand | Mreeco |
|---|---|
| Category | Components |
| SKU | 637718987688453090 |
| Availability | In stock |
