  2. Dual Shaft 0.6 Degree/Step 3 Phase Hybrid Stepper Motor NEMA 17
Dual Shaft 0.6 Degree/Step 3 Phase Hybrid Stepper Motor NEMA 17 - Front View
Mreeco

Dual Shaft 0.6 Degree/Step 3 Phase Hybrid Stepper Motor NEMA 17

SKU: 637739627880609202Category: Industrial Motors
Rs 400

In stock

KT42JM06-551, KT SERIES, TypeKT Series, 3 phase Hybrid Stepping MotorProduct TypeStepper MotorSeries3 Phase KTMotor Frame SizeNEMA 17No. of Phases3Step Angle0.6 deg./stepVoltage3.12 VCurrent per 2 Phase2.4 AWinding ...

Ask about this product on WhatsApp
  • Fast deliveryFree shipping on prepaid orders above Rs. 10,000
  • Secure payment100% secure payments by Meezan Bank
  • SupportMonday to Saturday, 11:00 AM to 8:00 PM
  • ReturnsSee our return and refund policy

Description

KT42JM06-551, KT SERIES,

Type

KT

Series

, 3 phase Hybrid Stepping Motor Product

Type

Stepper Motor

Series

3 Phase KT

Motor Frame Size

NEMA 17

No. of Phases

3

Step Angle

0.6 deg./step

Voltage

3.12 V

Current per 2 Phase

2.4 A

Winding Resistance/2 Phase

1.30 Ω

Inductance/2 Phase

1.3 mH

Holding Torque

25.5 oz·in180 mN·m

Detent Torque

1.1 oz·in8 mN·m

Standard Size

42 x 40 mm1.65 x 1.58 in.

Rotor Inertia

60 g·cm²0.33 oz·in²

Drive Method

Bipolar

Weight

310 g0.68 lb

Insulation Class

Jis Class E (120ºC/248ºF) (UL Value : Class B 130ºC/266ºF)

Insulation Resistance (Motor Section)

500 VDC, 100 MO min.

Dielectric Strength

500 VAC, 50 HZ, 1 min.

Operating Temperature Range

-10 to 50 ºC

Allowable Temperature Rise

70 ºK

Specifications

BrandMreeco
CategoryIndustrial Motors
SKU637739627880609202
AvailabilityIn stock

Shipping & Returns

Delivery across Pakistan. Free shipping on prepaid orders above Rs. 10,000.

Please read our return and refund policy before ordering.

Dual Shaft 0.6 Degree/Step 3 Phase Hybrid Stepper Motor NEMA 17 Rs 400
