Description
Features of UNI-T UT12D-ROW AC Voltage Detector:
- Auto power off
- Buzzer
- LED indication
- AC voltagedetection
- High/Low voltagemode
Applications of UNI-T UT12D-ROW AC Voltage Detector:
- Low voltage mode: Low-voltage motor (<90V), audio systems, arc welding machines,underground mining lighting, cables with thick insulation layer and other weakelectromagnetic AC signals.
- High voltage mode: Urban electric supply and three-phase systems (90~1000V). Forexample, power distribution units, electrical panels, electrical appliances.
Technical Specifications of UNI-T UT12D-ROW AC Voltage Detector:
| Specifications | |
| Model | UT12D-ROW |
| AC voltage (Low) | 24V~1000V |
| AC voltage (High) | 90V~1000V |
| Frequency range | 50/60Hz |
| Built-in flashlight | √ |
| ※Audible (buzzer) and visual (LED) indication | √ |
| Buzzer | √ |
| LED indication | √ |
| Auto power off | √ |
| Low voltage indication | √ |
| Drop test | 1m |
| General Characteristics | |
| Power | 1.5V battery (R03) x 2 |
| Product color | Red and grey |
| Product net weight | 50g |
| Product size | 150mm x 18 mm x 23mm |
| Standard accessories | Batteries |
| Standard individual packing | Blister, English manual |
| Standard quantity per carton | 40pcs |
| Standard carton measurement | 350mm x 245 mm x 210mm |
| Standard carton gross weight | About 3.6kg |
