| Specifications |
Range |
UT243 |
| AC current (A) |
1000A |
±(2%+5) |
| AC voltage (V) |
600V |
±(1.2%+5) |
| Frequency (Hz) |
40Hz~80Hz |
±(0.5%+5) |
| Active power (W) |
0.01kW~600kW |
±(3%+5) |
| Apparent power (VA) |
0.01kVA~600kVA |
±(3%+5) |
| Reactive power (VAr) |
0.01kVAr~600kVAr |
±(4%+5) |
| Power factor |
0.3~1 |
±0.022 |
| Phase angle (°) |
0°~360° |
±2° |
| Active energy (Wh) |
1kWh~9999kWh |
±(3%+2) |
| Features |
| Display count |
|
10000 |
| Auto range |
|
√ |
| Jaw opening |
|
50mm |
| True RMS |
AC voltage/AC current |
√ |
| Auto power off |
|
√ |
| Low battery indication |
|
√ |
| Data hold |
|
√ |
| MAX/MIN |
|
√ |
| Data storage |
|
999 |
| USB interface |
|
√ |
| LCD backlight |
|
√ |
| Full icon display |
|
√ |
| Harmonic analysis |
|
1~20 |
| Setup |
|
√ |
| Single-phase 2-wire |
|
√ |
| 3-phase 3-wire |
|
√ |
| 3-phase 4-wire |
|
√ |
| Phase sequence test |
Positive phase, reverse phase, phase deficiency |
√ |
| Input impedance for DCV |
|
≥5MΩ |
| Input protection |
|
√ |
| General Characterisitics |
| Power |
1.5V battery (R6) x 4 |
| Display |
46mm x 42mm |
| Product color |
Red and grey |
| Product net weight |
601g |
| Product size |
303mm x 112mm x 39mm |
| Standard accessories |
Batteries, test leads, alligator clips, USB interface cable, PC software CD |
| Standard individual packing |
Gift box, English manual, tool box |
| Standard quantity per carton |
5pcs |
| Standard carton measurement |
510mm x 375mm x 320mm |
| Standard carton gross weight |
12.3kg |
