| Specifications |
Type |
Range |
Accuracy |
| Source accuracy |
| DC mV |
|
100.000mV |
±(0.05%＋20) |
| |
1000.0mV |
±(0.05%＋3) |
| Resistance (Ω) |
|
500.0Ω |
±(0.05%+2) |
| |
5000Ω |
±(0.05%+2) |
| Thermocouples |
J |
-20~1200℃ (-328~2192℉) |
±0.7℃ |
| K |
-200~1370℃ (-328~2498℉) |
±1℃ |
| T |
-200~400℃ (-328~752℉) |
±0.8℃ |
| E |
-200~950℃ (-328~1742℉) |
±0.7℃ |
| R |
-20~1750℃ (-4~3182℉) |
±1.4℃ |
| S |
-20~1750℃ (-4~3182℉) |
±1.5℃ |
| B |
600~1800℃ (1112~3272℉) |
±1.4℃ |
| N |
-200~0~1300℃ (-328~2372℉) |
±0.9℃ |
| Wre325 |
0~2000℃ (32~3632℉) |
±1.8℃ |
| Wre526 |
0~2300℃ (32~4172℉) |
±1.8℃ |
| RTDs |
Pt10 |
-200~850℃ (-328~1562℉) |
±(0.5%+6℃) |
| Pt100 |
±(0.05%+0.6℃) |
| Cu50 |
-50~150℃ (-58~302℉) |
±(0.05%+0.6℃) |
| Cu100 |
±(0.05%+0.6℃) |
| Features |
| Ramp functions |
Source functions: Voltage, resistance, temperature |
| Ramps: Slow ramp, fast ramp, 25% step-ramp |
| Step functions |
Source functions: Voltage, resistance, temperature |
| Steps: 25% of range, 100% of range |
| General Characterisitics |
| Power |
9V battery (6F22) |
| Display |
63mm x 40mm |
| Product color |
Red and grey |
| Product net weight |
410g |
| Product size |
96mm x 193mm x 47mm |
| Standard accessories |
Test leads, battery |
| Standard individual packing |
Gift box, English manual, cloth bag |
| Standard quantity per carton |
5pcs |
| Standard carton measurement |
325mm x 225mm x 285mm |
| Standard carton gross weight |
4.5kg |
