| Model |
UTG4162A |
| Bandwidth |
160MHz |
| Channels |
2 |
| Sampling rate |
500MS/s |
| Waveforms |
Sine, square, ramp, harmonic, pulse, noise, DC voltage, arbitrary |
| Working modes |
Output on/off, continuous, modulation, sweep, burst |
| Modulations |
AM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, OSK, PWM, SUM, QAM |
| Frequency Characteristics |
| Sine |
1μHz~160MHz |
| Square/Pulse |
1μHz~50MHz |
| Slope |
1μHz~4MHz |
| Harmonic |
1μHz~80MHz |
| Noise (-3dB) |
160MHz bandwidth |
| Resolution |
1μHz |
| Arbitrary Waveform |
| Frequency range |
1μHz~40MHz |
| Length |
8~32Mpts |
| Vertical resolution |
16 bits |
| Min rise/fall time (typical: 1Vpp) |
<5ns |
| General Characteristics |
| Power |
100V~240V ACrms, 50Hz/60Hz |
| Display |
8-inch TFT LCD, WVGA (800 x 480) |
| Product color |
White and grey |
| Product net weight |
3.5kg |
| Product size |
336mm x 164mm x 108mm |
| Standard accessories |
BNC-BNC cable x 2, USB interface cable, PC software CD, power cord |
| Standard individual packing |
Carton box |
| Standard quantity per carton |
1pcs |
| Standard carton measurement |
405mm x 225mm x 265mmv |
| Standard carton gross weight |
4.8kg |
