| Specifications |
Range |
UT161D |
| Certifications (UT161 Series only) |
CE/RoHS/cETLus |
| Safety ratings |
CAT III 1000V/CAT IV 600V |
| AC voltage (V) |
1000V |
±(1%＋3) |
| DC voltage (V) |
1000V |
±(0.5%＋3) |
| AC current (A) |
10A |
|
| 20A |
±(1.2%＋5) |
| DC current (A) |
10A |
|
| 20A |
±(1%＋2) |
| Resistance (Ω) |
60MΩ |
±(1%＋2) |
| 220MΩ |
|
| Capacitance (F) |
60mF |
±(3%＋5) |
| 220mF |
|
| Frequency (Hz) |
10MHz |
±(0.1%＋4) |
| 220MHz |
|
| Duty cycle (%) |
0.1%~99.9% |
±(2%＋5) |
| Temperature (℃/℉) |
-40℃~1000℃ |
±(1%＋3) |
| -40℉~1832℉ |
±(1%＋6) |
| Display count |
|
6000 |
| Bandwidth (Hz) |
|
40Hz~1kHz |
| LPF ACV |
|
|
| LoZ ACV |
|
√ |
| ACV+DCV |
|
|
| Transistor hFE |
|
|
| Peak Hold |
|
√ |
| Analog bar |
|
31 |
| General Characteristics |
| Power |
1.5V battery (R03) x 4 |
| Product net weight |
350g |
| Product size |
190mm x 90mm x 50mm |
| Standard accessories |
Battery, gold plated test leads, USB cable, temperature probe, English manual |
| Standard individual packing |
Gift box, cloth bag |
| Standard quantity per carton |
20pcs |
| Standard carton measurement |
480mm x 370mm x 325mm |
| Standard carton gross weight |
17.8kg |
| Optional accessories |
Bluetooth/APP |
