| Specifications |
Range |
UT61E+ |
| Certifications (UT161 Series only) |
CE/RoHS/cETLus |
| Safety ratings |
CAT III 1000V/CAT IV 600V |
| AC voltage (V) |
1000V |
±(0.8%＋10) |
| DC voltage (V) |
1000V |
±(0.05%＋5) |
| AC current (A) |
20A |
±(0.8%＋10) |
| DC current (A) |
20A |
±(0.5%＋10) |
| Resistance (Ω) |
220MΩ |
±(0.5%＋10) |
| Capacitance (F) |
220mF |
±(3%＋5) |
| Frequency (Hz) |
220MHz |
±(0.01%＋5) |
| Duty cycle (%) |
0.1%~99.9% |
±(2%＋5) |
| Display count |
|
22000 |
| Bandwidth (Hz) |
|
40~10kHz |
| LPF ACV |
|
√ |
| ACV+DCV |
|
√ |
| Transistor hFE |
|
√ |
| Peak Hold |
|
√ |
| Analog bar |
|
46 |
| General Characteristics |
| Power |
1.5V battery (R03) x 4 |
| Product net weight |
350g |
| Product size |
190mm x 90mm x 50mm |
| Standard accessories |
Battery, gold plated test leads, USB cable, temperature multi-purpose socket, English manual |
| Standard individual packing |
Gift box, cloth bag |
| Standard quantity per carton |
20pcs |
| Standard carton measurement |
480mm x 370mm x 365mm |
| Standard carton gross weight |
15.2kg |
| Optional accessories |
Bluetooth/APP |
