| Specifications |
Range |
UT892 |
| DC voltage (V) |
6.000V/60.00V/600.0V/1000V/2000V |
±(0.5%+3) |
| AC voltage (V) |
6.000V/60.00V/600.0V/1000V/2000V |
±(1.0%+3) |
| Variable frequency voltage (VFC) |
600V |
±(5%) |
| Frequency (Hz) |
10Hz~10kHz |
±(0.5%+2) |
| Resistance (Ω) |
600.0Ω/6.000kΩ/60.00kΩ/6.000MΩ/60.00MΩ |
±(0.5%+5) |
| Capacitance (F) |
60.00nF/600.0nF~600.0μF/6000μF/60mF |
±(3.0%+10) |
| Features |
| Display counts |
|
6000 |
| Auto/manual range |
|
√ |
| NCV |
|
√ |
| LIVE test |
|
√ |
| Diode |
|
√ |
| Continuity |
|
√ |
| Low battery indication |
≤ Approximately 2.5V |
√ |
| Data hold |
|
√ |
| Max/Min |
|
√ |
| Relative mode |
|
√ |
| Auto power off |
Approximately 15 minutes |
√ |
| Backlight |
|
√ |
| Safety rating |
CAT II 1000V/CAT III 600V |
√ |
| General Characteristics |
| Power |
AA 1.5V x2 |
| Product color |
Red+Gray |
| Product net weight |
350g (Including batteries) |
| Product size |
187*88*56mm |
| Standard accessories |
English manual, test leads, batteries. |
| Standard individual packing |
Gift box |
| Standard quantity per carton |
40 pcs |
| Standard carton measurement |
645×450×350mm |
